UAD149A 3BHE014135R2011 excitation control unit
Brand:ABB
Model:UAD149A 3BHE014135R2011
Product status: New
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
UAD149A 3BHE014135R2011 excitation control unit
Product manual:
Detailed introduction of ABB UAD149A 3BHE014135R2011 excitation control unit (excluding external links):
🧩 Basic information
model: UAD149A
Material Number: 3BHE014135R2011
manufacturer: ABB
Product Category: Excitation Control Module
Application areas: Synchronous generator excitation system, power plant automation control system
⚙️ Functional Features
High performance control core:
Adopting ABB AC 800PEC control platform, it integrates high-speed digital signal processing with the reliability of traditional PLC.
Specially designed for excitation systems with high requirements for dynamic response.
Powerful programming skills:
Support IEC 61131-3 standard language programming (via Control Builder M)
Compatible with MATLAB/Simulink programming environment and supports Simulink Coder for automatic code generation.
Rich I/O interfaces:
Digital input: 8 channels
Digital output: 8 channels
Other analog/digital interfaces can be configured for connection with generators and excitation devices.
Communication ability:
Support S800 I/O module bus and use fiber optic for high-speed communication.
Expandable communication module through CEX bus, suitable for field buses such as MODBUS and PROFIBUS.
Third party protocol integration can be supported through the Anybus-S plugin.
System reliability:
Real time control with fast response and strong anti-interference ability.
Support redundant design (such as multi-channel power supply or dual controller configuration).
Strong environmental adaptability:
Working temperature:- 40 ° C to+70 ° C
Storage temperature:- 40 ° C to+85 ° C
Relative humidity: 5% to 95% (without condensation)
🧱 Application scenarios
Synchronous generator excitation system in hydropower and thermal power plants
Industrial large-scale synchronous motor control system
Power plant automation system renovation or upgrade project
Power electronic control environment with high reliability and dynamic performance requirements
