Siemens 6ESC214-1BC00-0XB0 Central Processing Unit

Brand:Siemens
Model:6ES7214-1BC00-0XB0
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Siemens 6ESC214-1BC00-0XB0 Central Processing Unit

Product manual:

Siemens 6ES7214-1BC00-0XB0 is the CPU 226 AC/DC/Relay Central Processing Unit (CPU) in the SIMATIC S7-200 series.
This module has powerful processing capabilities and flexible expansion options, making it suitable for medium to large-scale automation tasks, especially in applications that require high I/O points and complex control functions.
Main technical specifications:
Type: SIMATIC S7-200 CPU 226 AC/DC/Relay
Input/output points:
24 digit input
16 digital outputs (relay outputs)
Power supply voltage: AC power supply, with a voltage range of 85V to 264V AC.
Storage capacity:
Program memory: 24 KB
Data storage: 10 KB
Communication interface:
2 RS-485 interfaces: Supports PPI (point-to-point communication), MPI (multi-point communication), and Freeport mode.
Loop time: The basic instruction execution time is 0.22 microseconds per instruction, supporting fast response control tasks.
Scalability: Supports up to 7 expansion modules, which can increase the number of input/output points or other functional modules.
Working temperature: Suitable for industrial environments ranging from 0 ° C to 55 ° C.
