Siemens 6ES7322-1FL00-0AA0 Digital Output Module

Product manual:

Main technical specifications:
Number of output channels: 32 digital outputs
Output voltage: 24V DC
Maximum output current: 0.5 A per channel
Total output current: Maximum 8 A (when all channels are used together)
Protection level: IP20 (suitable for installation inside control cabinets)
Electrical isolation: There is electrical isolation between the output signal and the backplane bus, usually 500V AC
Response time: Typical 1 ms (variable depending on load)
Functional features:
High density output: Provides 32 output channels, suitable for application scenarios that require multiple output controls, saving space and costs.
Short circuit protection: It has a short circuit protection function, which can automatically cut off the power supply when the output channel fails, protecting the module and load.
LED status indicator light: Each output channel is equipped with an LED indicator light, which displays the output status in real time for easy monitoring and troubleshooting.
Electrical isolation: The electrical isolation design between the output and the controller backplane ensures the safety and stability of system operation and reduces interference risks.
High reliability: The module design is suitable for harsh environmental conditions and has high anti-interference ability and reliability.
Application scenarios:
Factory automation: used to control multiple solenoid valves, relays, lighting fixtures, and other low-voltage equipment to achieve automated operations in factories.
Process control: Control process equipment in fields such as chemical, pharmaceutical, and food processing to ensure precise automation control.
Building automation: controlling lighting, air conditioning, ventilation and other facilities to improve the efficiency of building management and optimize energy use.
Mechanical manufacturing: In automated machinery, it is used for multi-point control to ensure that equipment can operate according to plan.

Product details picture:
