Siemens 6ES7322-1FH00-0AA0 Digital Output Module

Brand:Siemens
Model:6ES7322-1FH00-0AA0
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Siemens 6ES7316-1AG00-0AB0 processor

Product manual:

Main technical specifications:
Number of output channels: 16 relay outputs
Output type: Relay normally open (NO) contact
Output voltage:
Maximum 230V AC
Maximum output current: 5A per channel (suitable for AC and DC loads)
Switching capacity:
AC load maximum 2000 VA
DC load maximum 150 W
Protection level: IP20 (suitable for installation in control cabinets)
Electrical isolation: There is electrical isolation (500V AC) between the output channel and the backplane bus
Functional features:
16 relay outputs: Provides 16 independent relay output channels, each of which can control AC/DC loads up to 5A.
Relay design: The relay contacts are normally open (NO) and can directly control high-power devices such as motors, solenoid valves, and lighting fixtures.
High load capacity: Suitable for controlling high-power equipment in industrial environments, especially high current loads that require frequent switching.
Short circuit protection: Built in short circuit protection function to prevent module damage under fault conditions.
Electrical isolation: The electrical isolation between the output signal and the backplane bus ensures system stability and reduces external interference.
LED status indicator light: Each output channel is equipped with LED indicator lights to monitor the channel status in real-time, making it easy to debug and maintain.
Compact design: Compact size, suitable for automation control systems that require high-density output.
Application scenarios:
Factory automation: Control high-power loads such as motors, solenoid valves, heaters, etc. in industrial equipment to achieve automated operations.
Process control: In industries such as chemical, pharmaceutical, and food processing, control complex process equipment to ensure stable production processes.
Building automation: used in building management systems to control lighting, air conditioning, heating and other equipment, and optimize energy management.
Mechanical manufacturing: Control the motors and actuators in mechanical automation systems to ensure reliable operation of equipment.

Product details picture:
