Siemens 6ES7322-1FF01-0AA0 Relay Output Module

Brand:Siemens
Model:6ES7322-1FF01-0AA0
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Siemens 6ES7322-1FF01-0AA0 Relay Output Module

Product manual:

Siemens 6ES7322-1FF01-0AA0 is a relay output module used in S7-300 series PLC systems, providing 8 relay outputs and suitable for controlling high voltage or high current loads.
Main technical specifications:
Number of output channels: 8 relay outputs
Contact type: normally open (NO) contact
Output voltage:
Maximum 230V AC

Maximum output current:
5A (AC voltage) per channel
5A (DC voltage) per channel
Switching power: Maximum 2000 VA (AC load) or 150 W (DC load)
Protection level: IP20 (suitable for installation inside control cabinets)
Electrical isolation: There is electrical isolation (500V AC) between the output channel and the backplane bus
Functional features:
Relay output: Provides 8 relay output channels, which can directly drive high voltage or high current loads, suitable for controlling equipment such as motors, solenoid valves, heaters, etc.
High load capacity: Each channel supports up to 5A load current, suitable for high-power load control.
Contact durability: Relay contact design has a high mechanical and electrical lifespan, suitable for applications that require frequent operation.
Application scenarios:
Factory automation: used to control the start/stop of large equipment such as motors, solenoid valves, or pumps.
Process control: Used in process control systems in industries such as chemical and pharmaceutical to drive heaters, fans, or other power equipment.
Building automation: Control high-power equipment such as lighting, air conditioning, and power supply systems to ensure efficient operation of building systems.
Mechanical manufacturing: In industrial machinery automation systems, directly controlling the power supply of equipment is suitable for high voltage or high current execution devices.
