Siemens 6ES7322-1EH01-0AA0 Digital Output Module

Product manual:

Number of output channels: 32 digital outputs
Output voltage: 24V DC
Maximum output current: 0.5 A per channel
Total output current: 1 A maximum (every 16 output channels)
Output type: Suitable for low-voltage DC loads (such as solenoid valves, relays, etc.)
Isolation voltage: 500V AC (isolation between output and backplane bus)
Protection level: IP20 (suitable for installation inside control cabinets)
Electrical isolation: There is electrical isolation between the output signal and the backplane bus to ensure signal transmission safety and enhance anti-interference capability.
Functional features:
32 output channels: Provides 32 independent 24V DC digital output channels, suitable for large-scale device control needs.
Short circuit protection: It has a short circuit protection function to ensure that relevant channels can be automatically closed in case of circuit failure, preventing module or equipment damage.
Electrical isolation: There is a 500V electrical isolation between the output channel and the backplane bus, which enhances the module's ability to resist electromagnetic interference and ensures system stability.
LED status indicator light: Each channel has an LED indicator light that displays the output status, making it convenient for real-time monitoring and troubleshooting.
High density design: Compact module design enables it to provide more output channels in limited space, saving control cabinet space.
Application scenarios:
Factory automation: In large-scale automated production lines, it is used to control solenoid valves, relays, and other actuators to achieve automated operations.
Process control: Used in process control systems that require multi-point control to drive multiple devices and ensure precise execution of operational instructions.
Building automation: suitable for controlling multiple lighting, ventilation, air conditioning and other equipment in building management systems to achieve centralized control.
Mechanical manufacturing: In large-scale mechanical manufacturing and automation systems, it is used to control multiple executing devices or sensors.

Product details picture:
