Siemens 6ES7322-1BH00-0AA0 Digital Output Module

Product manual:

Main technical specifications:
Number of output channels: 16 digital outputs
Output voltage: 24V DC
Maximum output current: 0.5 A per channel
Total output current: maximum 4 A (8 channels per group)
Output type: Suitable for DC loads
Isolation voltage: 500V AC (between output and backplane bus)
Protection level: IP20
Electrical isolation: There is electrical isolation between the output channel and the backplane bus
Functional features:
16 output channels: Provides 16 independent 24V DC output channels, suitable for large-scale device control needs.
24V DC output: Standard 24V DC output, widely used in controlling solenoid valves, relays, actuators and other equipment.
Short circuit protection: Built in short circuit protection function ensures the protection of modules and connected devices from damage in case of circuit failure.
Electrical isolation: There is a 500V electrical isolation between the output and the backplane bus, enhancing the stability and safety of the module in industrial environments.
Overload protection: Supports overload protection function to avoid module damage caused by excessive output load and extend the service life of the system.
Modular design: Compatible with S7-300 series modular design, easy to integrate and expand, flexible to adapt to different industrial application needs.
Application scenarios:
Factory Automation: Suitable for controlling equipment on factory production lines, such as driving switches, relays, and actuators, to achieve automated production control.
Building automation: can be used for building automation control, such as the control of lighting systems and HVAC equipment.
Mechanical manufacturing: suitable for controlling mechanical equipment, driving various automated actuators, and supporting the automation needs of mechanized production.

Product details picture:
