Siemens 6ES7314-5AE10-0AB0 Central Processing Unit

Product manual:

Siemens 6ES7314-5AE10-0AB0 is a central processing unit (CPU) in the S7-300 series, with the specific model being CPU 314-2. This CPU module is suitable for various industrial automation and control applications, and has the following main features and technical specifications:
Main features:
Processing ability:
Adopting a 32-bit RISC architecture, it has efficient data processing performance and is suitable for complex control tasks and real-time applications.
Memory configuration:
Built in 512 KB RAM, capable of storing user programs and data, suitable for medium-sized application needs.
Support expanding storage to increase program and data storage capacity.
Input/Output Expansion:
Supports up to 32 I/O module connections, flexibly adapting to various automation needs.
Communication interface:
Integrating MPI and PROFIBUS communication interfaces facilitates efficient data exchange with other devices and enhances system integration capabilities.
Diagnostic function:
Built in fault detection and monitoring functions, real-time monitoring of system status for quick maintenance and troubleshooting.
Programming environment:
Programming is done through Siemens STEP 7 software, which supports multiple programming languages such as ladder diagrams, functional block diagrams, etc., making it easy to develop and debug.
Application areas:
Industrial automation: widely used in multiple fields such as machine control, production line monitoring, and process control.
Installation and configuration:
Installation: The module can be directly inserted into the S7-300 rack, supports hot swapping, and is easy to maintain and replace.
Configuration: Set up through STEP 7 software, supporting flexible system configuration to meet different application requirements.

Product details picture:
