Siemens 6ES7313-6BE00-0AB0 CPU module

Product manual:

Siemens 6ES7313-6BE00-0AB0 is a CPU 313C-2 DP module in the S7-300 series, which integrates a central processing unit (CPU) and multiple communication interfaces, suitable for small and medium-sized automation control systems. It has enhanced processing capabilities and flexible communication functions, which can support complex automation applications.
main features
Integrated I/O and DP interfaces:
The CPU 313C-2 DP module not only integrates a central processing unit, but also digital input/output and PROFIBUS DP master/slave interfaces, making control and communication more efficient.
Built in PROFIBUS DP interface:
Supports PROFIBUS DP communication protocol, which can be used as a master or slave to communicate with distributed devices, greatly improving the efficiency of distributed control systems.
Integrated digital I/O:
Contains 24 point digital input and 16 point digital output, suitable for direct control of field devices and reducing the need for additional I/O modules.
High speed processing capability:
Supports fast instruction processing, suitable for automation application scenarios that require high real-time performance and high response speed.
Modular design:
As part of the S7-300 series, it supports seamless integration with other modules (such as analog modules, communication modules, etc.) and flexible expansion of functionality.
Multiple programming languages supported:
Compatible with Siemens STEP 7 software, it can use programming languages such as ladder diagram (LAD), functional block diagram (FBD), and statement table (STL) to simplify the programming process.
Integrated diagnostic function:
Provide rich diagnostic functions that can quickly locate and eliminate system faults, improving the reliability of system operation.
technical specifications
Working memory: 64 KB
Loading memory: expandable to 8 MB (using MMC memory card)
Communication interface:
MPI (Multi Point Interface)
PROFIBUS DP master/slave interface
Integrated I/O:
24 point digital input (DI)
16 point digital output (DO)
Power supply voltage: 24 V DC
Processing speed: approximately 50 ns/instruction

Product details picture:
