Siemens 6ES7222-1BF00-0XA0 output module

Product manual:

Siemens 6ES7222-1BF00-0XA0 is a digital output module in the SIMATIC S7-200 series, used to expand the digital output capabilities of PLC systems and control external devices such as motors, relays, and actuators.
Main technical specifications:
Product model: 6ES7222-1BF00-0XA0
Module type: Digital output module
Number of output channels:
16 digital outputs, supporting 24V DC signals.
Output voltage:
24V DC, compliant with standard industrial digital output voltage.
Output current:
The maximum output current of each channel is 0.5A, and the total current can reach 8A.
Short circuit protection:
Built in short-circuit protection to prevent output overload.
Electrical isolation:
There is electrical isolation between the output channel and the PLC system to enhance anti-interference capability.
Installation method:
Supports DIN rail installation for easy integration into industrial control cabinets.
Size:
Width: 71.2 mm
Height: 80 mm
Depth: 62 mm
Main features:
16 digital outputs:
Provides 16 independent digital output channels for flexible control of various external devices.
Fast response time:
The module has fast response characteristics and is suitable for control scenarios that require high output timeliness.
Short circuit protection function:
Built in short-circuit protection mechanism ensures the safety of equipment in case of malfunction and reduces the risk of damage.
Electrical isolation design:
The electrical isolation between the channel and PLC system enhances the stability and reliability of the system.
Modular Expansion:
The module design is compact and can be easily extended to existing S7-200 systems to increase output capacity.

Product details picture:
