Siemens 6ES7221-1JF00-0XA0 Analog Input/Output Module
Product manual:
Siemens 6ES7221-1JF00-0XA0 is an analog input/output module of the SIMATIC S7-200 series, used to expand the analog signal processing capabilities of PLC systems.
This module is capable of processing analog input and output signals, such as current and voltage signals from sensors, as well as controlling the output of analog devices such as frequency converters or regulating valves.
Main technical specifications:
Product model: 6ES7221-1JF00-0XA0
Module type: Analog input/output module
Input/output channels:
4-channel analog input: can receive 0-10V voltage or 0-20mA current signals.
1-channel analog output: capable of outputting 0-10V voltage or 0-20mA current signals.
resolving power:
The resolution of input and output is 10 bits to ensure the accuracy of signal processing.
Input range:
Voltage: 0-10V
Current: 0-20mA
Output range:
Voltage: 0-10V
Current: 0-20mA
Electrical isolation:
There is electrical isolation between the input/output channels and the PLC system to ensure the system's anti-interference ability and stability.
Installation method:
Supports DIN rail installation and is suitable for integration into standard industrial control cabinets.
Size:
Width: 71.2 mm
Height: 80 mm
Depth: 62 mm
Product details picture:
