Siemens 6ES7143-1BF00-0XB0 electronic module

Product manual:

Siemens 6ES7143-1BF00-0XB0 is an electronic module of the S7-1200 series, mainly used in industrial automation systems. The following are the key features and specifications of this module:
Basic characteristics
Type: Analog Input/Output Module
Input/output channels: 6 analog input channels and 2 analog output channels
Signal type: Supports voltage and current signals
technical specifications
Input voltage range: 0 to 10 V, -10 to+10 V, or 0 to 20 mA
Output voltage range: 0 to 10 V or 0 to 20 mA
Resolution: typically 12 bits
Sampling time: The sampling time for each channel is approximately 1 ms
Environmental temperature range: Operating temperature range is -20 ° C to+60 ° C
Installation and wiring
Module size: 70 mm x 100 mm x 75 mm
Installation method: DIN rail installation
Wiring method: screw terminal, suitable for various cable types
application area
This module is widely used in process control, automation systems, and manufacturing industries, and is suitable for collecting and controlling analog signals.

Product details picture:
