Siemens 6ES5434-4UA12 Digital Input Module

Product manual:

Main features:
Model: 6ES5434-4UA12
Series: SIMATIC S5
Module type: Digital Input Module
Function:
Signal reception: Receive switch signals from external devices such as switches and sensors.
Signal conversion: Convert external digital signals into signals that can be processed by PLC.
Data collection: Provide input signals to PLC for data processing, control, and monitoring.
Application scenarios:
Industrial automation: In automation control systems, it is used to collect switch signals, control equipment or monitor status.
Process control: used to collect switch status signals during the production process, such as limit switches, buttons, etc.
Data collection: used to transmit signals from various sensors and switches to PLC for further data processing and control decision-making.
Technical specifications:
Channel count: Typically provides multiple input channels, specifically 16 digital input channels.
Input signal type: Supports 24V DC switch signal, compatible with industrial standard voltage.
Electrical specifications:
Input voltage: typically 24V DC.
Current specification: The input current of each channel is usually within the range of mA.
Interface standard: Compliant with SIMATIC S5 series interface standards and compatible with other S5 series modules.
Installation and use:
Installation: Install the 6ES5434-4UA12 input module into the SIMATIC S5 series rack and make electrical connections through the rack's backplane.
Configuration: Use STEP 5 programming software to configure the module, including setting input channel parameters.
Debugging: After installation, system debugging is required to ensure that the module can correctly receive and process input signals.

Product details picture:
