SIEMENS 6ES5430-4UA14 Digital Input Module

Product manual:

Main features:
Series: S5 Series
Model: 6ES5430-4UA14
Type: Digital Input Module
Number of input channels: 16 digital input points
Input voltage: 24V DC (direct current)
Function:
Receive digital signals (such as status signals of buttons, switches, and sensors)
Transmit these input signals to the PLC system for subsequent logic control
Signal type: binary (high/low, on/off)
Application scenarios:
Industrial automation: used to monitor the status of various on-site devices, such as start/stop buttons, limit switches, proximity sensors, etc., which is very common in manufacturing and factory automation.
Process control: By monitoring the digital input status of devices or systems in real-time, ensure that the system responds correctly based on input signals.
Equipment status monitoring: helps the control system collect working status signals of on-site equipment.
Technical parameters:
Input voltage: 24V DC, standard industrial signal voltage
Number of input channels: 16 independent input channels, used to connect multiple input devices
Response speed: The module can quickly respond to input signals and is suitable for applications that require real-time monitoring
Isolation: There is electrical isolation between module channels to ensure the safety and stability of signal transmission
compatibility:
Applicable system: Compatible with Siemens S5 series PLC system, suitable for control systems such as S5-115U, S5-135U, S5-155U, etc.
Module installation: It can be installed in the S5 series rack and work together with other modules to achieve complete automation control.
Precautions for use:
Wiring requirements: When connecting external devices, ensure that the signal voltage is 24V DC to avoid faults caused by mismatched input voltages.
Signal interference: Electromagnetic interference in industrial environments may affect signal quality, so it is recommended to use shielded cables or other protective measures in environments with high electrical noise.
Regular maintenance: Regularly check the working status of modules and connected devices to ensure accurate signal transmission.

Product details picture:
