Siemens 6ES5243-1AB12 Analog Input Module

Product manual:

Main features:
Module type: Analog input module
Series: SIMATIC S5 series, typically suitable for systems such as S5-115U, S5-135U, and S5-155U.
Input signal type: Supports multiple analog signal inputs, including voltage signals (such as 0-10V), current signals (such as 4-20mA), etc.
Input channel: Usually provides multi-channel input for simultaneously receiving multiple analog signals, with the specific number of channels depending on the module specifications.
Resolution: With high-precision analog-to-digital conversion function, it ensures precise signal processing.
Sampling rate: Supports fast signal sampling and is suitable for real-time monitoring of dynamic process variables.
Communication interface: Communicate with the CPU module through the system bus, and transmit the collected analog data to the PLC for processing and control.
Function and purpose:
Analog signal acquisition: This module receives analog signals from external devices (such as sensors, transmitters, etc.)

and converts them into digital signals for processing by the PLC system.
Process monitoring and control: used to monitor real-time data of process variables such as temperature, pressure,

liquid level, flow rate, etc., supporting automated operations in process control.
Data recording and analysis: capable of collecting and recording the trend of process variables, supporting the analysis and optimization of production processes.
Alarm and protection functions: Combined with the PLC system, based on real-time changes in analog signals,

alarm or trigger protection measures can be set to ensure the safe operation of the system.
Application scenarios:
Process automation: Suitable for industrial systems that require precise measurement and control of process variables, such as chemical, pharmaceutical, food processing, and other fields.
Environmental monitoring: In situations where real-time monitoring of environmental parameters such as temperature,

humidity, pressure, etc. is required, the analog input module is a key component.
Production line control: used for collecting various sensor signals in industrial production lines to achieve precise monitoring and adjustment of equipment status.
Energy management: In energy systems, analog input modules can be used to monitor parameters such as voltage,

current, and power, helping optimize energy use.

Product details picture:
