Siemens 6ES5-420-7LA11 Digital Input Module

Product manual:

Siemens 6ES5-420-7LA11 is a digital input module of the Siemens S5 series. The following is the detailed information of the module:
Siemens 6ES5-420-7LA11 Digital Input Module
main features
Isolation protection: It has electrical isolation function to protect the PLC system from external signal interference and electrical noise.
Response time: Provides fast response time to ensure timely processing of input signals.
Application scenarios
Automation control system: Receive digital signals from various sensors or switches in a PLC system for controlling and monitoring industrial processes.
Production line: used to detect the status or position on the production line, such as detecting the position of workpieces or the status of machines.
Device monitoring: Collecting status information of devices and providing feedback for automatic control or alarm.
Installation and operation
Installation: Install the digital input module into the rack of the Siemens S5 controller, ensuring that the module is properly docked and secured.
Connection: Connect the input signal line to the input port of the module, ensuring that the connection meets industry standards and specifications.
Configuration: Use Siemens' configuration tool (such as STEP 5 software) to set module parameters and ensure compatibility with the PLC system.
Debugging: Test the functionality of the input module to ensure that it can correctly receive and process input signals.

Product details picture:
