Siemens 6EP1436-3BA00 Switching Power Supply Module

Product manual:

The Siemens 6EP1436-3BA00 switching power module is a high-performance industrial power module in the Siemens SITOP PSU8200 series,
Specially designed for reliable 24V DC power supply, suitable for a wide range of industrial application scenarios.
This module is known for its high efficiency, stability, and compact design, and is one of the important power supply equipment in industrial automation systems.
main features
Efficient Design
Efficiency up to 95%, reducing energy loss and heat generation.
Supports a wide input voltage range and adapts to complex power supply environments.
Stable output
Provide stable 24V DC output, ensuring power continuity even in the event of input voltage fluctuations or brief power outages.
Integrate overload and short circuit protection to enhance system safety.
Compact and modular design
Compact design, space saving, suitable for installation inside control cabinets.
Modular structure, easy to integrate into existing systems.
Multi functional diagnosis and indication
Equipped with LED indicator lights, real-time display of operating status.
Support remote diagnostic function, monitor power supply status through external devices.
High reliability and durability
Industrial grade design, suitable for harsh environmental conditions such as high temperature, vibration, etc.
High MTBF (mean time between failures) reduces maintenance requirements.
technical specifications
Detailed parameter information
Product model 6EP1436-3BA00
Series SITOP PSU8200
Input voltage range 85V AC to 264V AC or 110V DC to 300V DC
Output voltage 24V DC
Maximum output current of 20A
Efficiency up to 95%
Protection functions include short circuit protection, overload protection, and overvoltage protection
Working temperature range -25 ° C to+70 ° C
Installation method: DIN rail installation
Dimensions 125 mm x 125 mm x 12

Product details picture:
