RTD IPWR104HRL100W power module
Product manual:
IPWR104HRL100W is an embedded power module produced by RTD Embedded Technologies, designed specifically for PC/104 systems, providing a reliable power solution.
Main features:
Input voltage range: Supports a wide input voltage range of 18-36V or 33-75V, suitable for various power supply environments.
Output power: Provides 100W output power, including:
+5V output, maximum current of 12A or 20A.
+12V output, maximum current 2.0A.
-12V output, maximum current 500mA.
Efficiency: Under full load conditions, the typical efficiency is at least 85%.
Working temperature range:- 40 ° C to+85 ° C, suitable for harsh environments.
Dimensions: Length 95.89mm, Width 90.17mm, Height 15.24mm.
Weight: Approximately 0.21kg.
Application areas:
This power module is widely used in the following fields:
Aviation and mobile devices: Due to their wide input voltage range and high efficiency, they are suitable for aviation electronic devices and mobile platforms.
Industrial systems: Provide stable power support in industrial automation and control systems.
Communication system: Provide reliable power supply for communication equipment to ensure stable operation of the system.
Military and Aerospace: Meet the high reliability and wide operating temperature range requirements of power modules in the military and aerospace fields.
The IPWR104HRL100W power module has become an ideal power solution for various embedded systems due to its high efficiency, reliability, and wide range of applications.
Product details picture:
