RadiSys CEQM67-2515-0 Single Board Computer Motherboard

Product manual:

main features
Supports multi-core processor architecture, providing powerful processing capabilities and efficient data processing.
Modular design
The design supports multiple extension modules and configuration options, allowing users to customize according to their application needs.
Provide multiple interfaces and extension options, supporting flexible system configuration and functional expansion.
Rich interfaces and extension options
Network interface: It includes multiple Ethernet interfaces and supports high-speed network connections.
Serial interface: Supports serial communication protocols such as RS-232 and RS-485.
USB interface: Provides multiple USB interfaces for external device connection.
PCIe slot: Supports PCIe expansion cards and provides additional functional expansion capabilities.
Storage interface: Provides SATA interface for connecting solid state drives (SSDs) or hard disk drives (HDDs).
Provide high stability and long lifespan, suitable for demanding industrial applications.
Powerful management and monitoring functions
Built in system management and monitoring tools, supporting remote management and fault diagnosis.
Provide real-time status monitoring and logging functions to help users track system operation.
technical specifications
processor
Model: Typically equipped with Intel Core i-series processors (such as i7, i5, i3) or other high-performance processors
Number of cores: Multi core processors to support high-performance computing
Memory
Supported memory types: DDR3 or DDR4
Maximum memory capacity: typically supports 8GB to 32GB or more
storage
Interface: Supports SATA interface for connecting solid state drives (SSDs) or hard disk drives (HDDs)
Storage capacity: Provide different storage options based on system configuration and requirements
Interfaces and extensions
Ethernet interface: Multiple Ethernet ports, supporting high-speed network connections
Serial interface: RS-232, RS-485
USB interface: Multiple USB 2.0/3.0 interfaces
PCIe slot: Supports PCIe expansion cards
Audio interface: may include audio input/output interface
environment condition
Working temperature range: typically 0 ° C to+60 ° C
Storage temperature range: -20 ° C to+85 ° C
Humidity: 5% to 95% non condensing

Product details picture:
