Radisys 46088611 axis motion control board

Product manual:

main features
High performance motion control
Precise control: Provides high-precision motion control, suitable for complex mechanical systems and automation equipment.
Multi axis support: Supports synchronous control of multiple axes, suitable for applications that require complex motion paths.
Flexible interfaces and scalability
Multiple interfaces: equipped with multiple input/output interfaces, supporting the connection of various sensors and actuators.
Scalability: Provides expansion slots, supports installation of additional functional modules, and increases system flexibility.
Industrial grade design
Anti interference: It has good anti electromagnetic interference ability, ensuring reliability in complex industrial environments.
Easy to configure and debug
Configuration tool: Provides configuration software and tools to simplify the system setup and debugging process.
User friendly: The interface is intuitive, making it easy for users to configure and operate the system.
technical specifications
Motion control
Number of axes: Supports control of multiple axes, with specific quantities varying depending on the model and configuration.
Control accuracy: Provides high-precision motion control, suitable for applications that require precise motion.
Interface and Connection
Input/Output Interface: Equipped with multiple I/O interfaces, such as digital input/output, analog input/output, etc., supporting various external device connections.
Communication interface: usually includes Ethernet interface, serial port, etc., used for data transmission and system communication.
Power requirements
Voltage Range: Supports standard industrial voltage ranges such as 24V DC, 48V DC, etc.
Power consumption: The power consumption design is energy-saving and suitable for the needs of industrial environments.
work environment
Working temperature: Designed to operate within a wide temperature range, such as -20 ° C to+60 ° C.
Humidity: Suitable for high humidity environments, usually providing moisture resistance.
control algorithm
Control mode: Supports multiple control modes, such as position control, speed control, torque control, etc.
Motion planning: Provides advanced motion planning algorithms that support control of complex paths and trajectories.

Product details picture:
