NI PXIE-5122 779967-03 High speed Digitizer Card

Brand: NI
Model:PXIE-5122 779967-03
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

NI PXIE-5122 779967-03 High speed Digitizer Card

Product manual:

NI PXIe-5122 (part number 779967-03) is a high-performance PXI Express oscilloscope module produced by National Instruments.
It provides two channels, with an analog bandwidth of 100 MHz, a sampling rate of up to 100 MS/s, and a resolution of 14 bits.
This device is suitable for time-domain and frequency-domain applications that require high-resolution, low-noise measurements.
Main features:
High resolution and low noise: Provides up to 14 bit resolution and low noise performance, ensuring accurate signal capture and analysis.
Flexible input configuration: supports multiple coupling, impedance, and voltage range settings to meet different application requirements.
Multiple triggering modes: including edge, digital, immediate, and software triggering modes, enhancing triggering flexibility.
Large capacity onboard memory: equipped with up to 512 MB of onboard memory, supporting long-term data acquisition.
Advanced synchronization and data streaming functions: Supports PXI synchronization and data streaming functions, suitable for multi-channel and mixed signal applications.
Application areas:
Radar and Ultrasonic Testing: Suitable for applications that require short trigger reload times, such as radar and ultrasonic testing.
Event recognition: performs well in applications that require capturing and analyzing rapid events.
