NI PXI-1033 multiplexer

Brand: NI
Model: PXI-1033
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

NI PXI-1033 multiplexer

Product manual:

The NI PXI-1033 multiplexer is a multiplexing module developed by National Instruments for use in testing and measurement systems,
Widely used in the fields of data collection and automated testing.
This device is designed for fast switching between multiple signal sources,
Allow users to simultaneously process data input or output from multiple channels, ensuring the efficiency and flexibility of the testing system.
Product Overview
model: NI PXI-1033
Type: Mux multiplexer
Series: PXI Series
Main purpose: Used to select input or output between multiple signal sources, commonly found in automation testing systems, data acquisition systems, and industrial control fields.
Support platform: PXI (PCI eXtensions for Instrumentation) standard, suitable for use with other PXI modules.
Key technical parameters
Parameter description
Number of channels: 8 or more, supporting the selection and switching of multiple input/output channels
Switching type: Single Pole Double Throw (SPDT) or Multiple Pole Multiple Throw (SPDT/DPDT), supporting high-precision switching
Input/output type: analog or digital signal, supporting multiple signal types (such as voltage, current, temperature, etc.)
Maximum switch speed supports fast switching, suitable for high-frequency testing scenarios
The working voltage range supports a wide voltage range, usually 3.3V to 12V, depending on the specific application
Slot type PXI slot, compatible with standard PXI measurement and control systems
The connection method supports standard PXI bus interfaces to ensure fast communication and data exchange with other modules
The working temperature range is -40 ° C to+70 ° C, suitable for working requirements under different environmental conditions
Mechanical dimension standard PXI module size, suitable for various testing racks and instrument systems
