Nagano ATM1613 Optical Encoder

Brand:Nagano
Model:ATM1613
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Nagano ATM1613 Optical Encoder

Product manual:

Main features:
High resolution:
Resolution: Nagano ATM1613 provides high-resolution output that can accurately measure rotation angles and positions,

typically with a resolution of up to one thousandth of a degree (i.e. up to several thousand pulses per revolution).
Accuracy: Provides high-precision angle and position measurements, suitable for application scenarios that require high-precision motion control.
Optoelectronic measurement technology:
Photoelectric sensing: Using photoelectric sensing technology to convert rotational motion into electrical pulse signals,

ensuring high accuracy and stability in the measurement process.
Encoder type: Generally an incremental encoder, which outputs pulse signals and is suitable for speed and position control.
Reliability and Durability:
Environmental adaptability: Designed for industrial environments, it has high resistance to vibration and impact.
Temperature range: able to operate stably within a wide temperature range and adapt to various industrial environments.
Signal output:
Output type: Typically provides standard A-phase, B-phase pulse signals, and Z-phase zero pulse signals, making it compatible with various control systems.
Electrical interface: Supports multiple electrical interfaces, such as TTL and HTL (high/low level), to meet different application requirements.
Installation and maintenance:
Installation method: Usually axial installation, suitable for standard industrial equipment and mechanical systems.
Easy to maintain: The design considers ease of maintenance and calibration, making it convenient for regular inspections and adjustments.
Technical parameters:
Working temperature: The typical working temperature range is -10 ° C to+70 ° C, which may vary depending on the specific model.
Power supply voltage: usually 5V or 12V DC power supply, specific voltage requirements depend on the model.
Output signal: Provides A-phase, B-phase pulse signals and Z-phase zero pulse signals, supporting TTL or HTL output.
Bearings: High precision bearings are used to ensure long-term stable operation and high-precision measurement.
