LAM 810-210775-002 AC power distribution module

Brand: LAM
Model: 810-210775-002
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

LAM 810-210775-002 AC power distribution module

Product manual:

The LAM 810-210775-002 AC power distribution module is one of the core electrical components in LAM Research equipment,
Specially designed for semiconductor manufacturing equipment, responsible for managing the AC power distribution of the equipment.
This module can efficiently and safely allocate and control the AC power required for equipment operation,
Simultaneously providing electrical protection functions to ensure the stability and reliability of the equipment.
Product Features
Efficient power distribution:
Distribute the main AC power to each subsystem or module of the equipment.
Supports multiple outputs to meet the power distribution needs of complex devices.
Overload protection:
Built in overload protection function, capable of automatically disconnecting the circuit when the current exceeds the safe range.
Provide short circuit and overcurrent protection to prevent electrical faults from causing damage to equipment.
Compact design:
Modular structure, easy to integrate into the device.
The compact design saves device space while maintaining efficient heat dissipation performance.
High reliability:
Using industrial grade components to adapt to the high demand environment of semiconductor manufacturing.
Support long-term trouble free operation to ensure continuous and efficient operation of the equipment.
Monitoring and Diagnosis:
Support real-time monitoring of power status (such as voltage and current).
Equipped with fault diagnosis function, it is easy to quickly locate problems.
Technical specifications (assuming reference)
Parameter Description
Input voltage of 200-240 VAC or standard voltage required by the equipment
Output channels 4-8 independent outputs
Maximum output current per channel 10A-30A (specific value to be confirmed)
Working frequency 50/60 Hz
Protection function overload, overcurrent, short circuit protection
Working temperature range: 0 ° C to 50 ° C
Interface type: standard terminal block or modular connector
Modular design of dimensions, in compliance with equipment installation standards
Certification in compliance with CE, UL, or other industry standards
