LAM 332-000474-000 Optical Expander Module

Product manual:

The LAM 332-000474-000 optical extender module is developed by LAM Research
A critical optical component in a device, typically used for optical signal processing or expanding related functions.
This type of module is widely used in semiconductor processing equipment, such as for monitoring
Measure and control the optical signals involved in the manufacturing process, such as photolithography, etching, or deposition processes.
Product Features
High precision optical performance:
Designed for high-resolution optical signal extension or adjustment, capable of accurately processing optical signals of multiple wavelengths.
Support optical monitoring or calibration functions under complex processes.
Modular integration:
Compact design, easy to integrate into optical subsystems of semiconductor manufacturing equipment.
It can seamlessly collaborate with other optical modules and control systems.
Durability and reliability:
Made with high-quality materials, it can withstand harsh process environments such as high temperatures and chemical corrosive atmospheres.
Optimized heat dissipation and anti-interference design ensure the long-term stable operation of the module.
Customizable:
Support customization of optical requirements for specific applications, such as specific wavelength ranges or expansion rates.
Flexible interface design allows for the adjustment of signal input/output formats according to system requirements.
Application flexibility:
The module can be used for optical signal transmission, power regulation, signal amplification, or other related functions.
Technical specifications (assuming reference)
Parameter description
Wavelength range 400 nm -1100 nm (or customized according to device requirements)
Expansion magnification options, such as 1x, 2x, 5x
Optical loss<0.5 dB (typical value)
Interface type: fiber optic interface or free space coupling
Working temperature range: 0 ° C to 70 ° C
Shell material: aluminum alloy or other corrosion-resistant materials
Customized size design to meet equipment integration requirements

Product details picture:
