DS3820PSCB1C1B Analog Input Module

Product manual:

2. Main characteristics
Multi channel analog input: This module supports multiple analog input channels and is suitable for applications involving multiple signal acquisition.
Wide input range: Supports standard analog signal input, such as 0-10V, 4-20mA, etc.
Strong anti-interference ability: Built in signal filtering and anti-interference design ensure that the module can work stably in complex industrial environments.
Modular design: Supports hot swapping, making it easy to maintain and expand the system.
3. Technical specifications
Analog input channels: 8 or 16 channels (depending on specific configuration)
Input signal type:
Voltage input: 0-5V, 0-10V
Current input: 4-20mA
Sampling accuracy: 12 bit or higher resolution analog-to-digital converter
Data transmission rate: high data refresh rate, adaptable to rapidly changing signal inputs
Working voltage: 24V DC
Working temperature range: -20 ° C to+60 ° C
Humidity range: 5% to 95% (no condensation)
4. Application Fields
Power plant: used for real-time monitoring and feedback control of key parameters such as temperature, pressure, and flow rate.
Petrochemical industry: Collect analog signals from sensors, and control systems adjust production processes based on input signals.
Automated production line: used to collect equipment working status parameters, achieve automatic control and optimization of the production process.
Building automation: Monitoring environmental parameters such as temperature and humidity in buildings, providing data support to optimize energy use.
5. Advantages and Value
High reliability: designed specifically for industrial applications, capable of stable operation in harsh environments.
Flexibility: Supports multiple types of analog signal inputs and can adapt to the access needs of various sensors and actuators.
Easy to maintain: Modular design supports online replacement and maintenance, reducing system downtime.
Precise control: The high-precision signal conversion capability ensures that the control system can accurately perform adjustment tasks.

Product details picture:
