DANAHER ZMP-SYNQNET-PCI Motion Control Module

Product manual:

DANAHER ZMP-SYNQNET-PCI is a high-performance PCI motion control module used in multi axis motion control systems,
Mainly used in precision automation, robotics, CNC machine tools, semiconductor manufacturing, electronic assembly and other fields.
It adopts SynqNet as the communication protocol, providing high-speed
Real time distributed motion control, suitable for high-precision synchronous control and applications with complex motion trajectories.
1. Product Overview
manufacturer: DANAHER Motion
Product model: ZMP-SYNQNET-PCI
Product type: PCI motion control module
Bus interface: PCI (standard 32-bit slot)
Communication Protocol: SynqNet (High bandwidth Real time Motion Control Network)
Typical applications:
Multi axis motion control (CNC machine tools, robots)
Electronic manufacturing, semiconductor equipment
3D printing, laser cutting, optical inspection
Automated assembly line
High precision positioning system
2. Main technical parameters
Parameter specifications
Communication interface PCI bus
Control Network SynqNet
Supports 4-32 axes (depending on configuration)
Data transmission rate up to 100Mbps
Synchronization accuracy nanosecond level (suitable for high-precision synchronization control)
I/O expansion compatible with external I/O modules
Feedback support supports multiple encoder feedbacks (incremental/absolute encoder)
Operating system compatibility with Windows/Linux (based on dedicated SDK)
Real time hardware level real-time performance, supporting motion trajectory planning
Typical control methods include position control, speed control, and torque control

Product details picture:
