CT-APS.22 Relay

Brand:ABB
Model:CT-APS.22
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

CT-APS.22 Relay

Product manual:

CT-APS.22 is an industrial grade solid-state relay (SSR) designed specifically for high-precision automation control. Adopting optoelectronic isolation technology to achieve complete electrical isolation of input and output, suitable for harsh industrial environments that require contactless switches.

2. Key parameters
Parameter specifications
Input control 3-32V DC (constant current)
Output specifications 24-480V AC/5-60A
Switch type zero crossing trigger (Z-type)
Isolation voltage 4000V RMS
Response time ≤ 10ms
Working temperature -30 ℃~+80 ℃
Installation method: DIN rail/screw fixation
Protection level IP20
3. Core Features
All solid state design: no mechanical contacts, lifespan>10 ⁸ times

Built in RC absorption circuit: effectively suppresses surge voltage (up to 1000V/μ s)

LED status indicator: input/output dual color display

Zero crossing trigger: reduce harmonic interference to the power grid

4. Typical applications
Temperature control system: PID control of electric heater

Packaging Machinery: Sealing Machine Temperature Adjustment

Power electronics: capacitor switching device

Special environment: Explosion proof occasions (used in conjunction with explosion-proof boxes)
