CDP312R 64378660G Control Panel

Brand:ABB
Model:CDP312R 64378660G
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

CDP312R 64378660G Control Panel

Product manual:

CDP312R 64378660G Control Panel Technical Description
1. Product Overview
model: CDP312R

Order number: 64378660G

manufacturer: ABB

Equipment type: Industrial frequency converter/driver dedicated control panel

Applicable series: ABB frequency converters such as ACS550/ACS580/ACS880

2. Core functions
Human computer interaction interface:

4-line LCD display (with backlight)

Multi functional navigation key+numeric keypad

Parameter configuration:

Real time monitoring of operating parameters (current, voltage, frequency, etc.)

Quickly modify driver parameters

Control operation:

Local start/stop control

Fault reset function

Status indication:

LED status light (running, fault, warning)

3. Technical parameters
Parameter specifications
Display area 4 lines x 20 characters (with backlight)
Communication interface RS485 (Modbus RTU protocol)
Protection level IP65 (front panel)/IP20 (rear)
Working temperature -10 ℃~+50 ℃
Storage temperature -25 ℃~+70 ℃
The power supply voltage is supplied through a frequency converter (24VDC)
Button lifespan ≥ 1 million operations
4. Interface definition
Interface Type Function Description
Connect the main communication interface to the frequency converter control terminal (RJ45)
Expansion interface can be optionally equipped with PC debugging interface
