CCC TMPU-1002 Conversion Module

Product manual:

The CCC TMPU-1002 conversion module is an industrial grade signal conversion module designed by Compressor Controls Corporation (CCC),
Dedicated to signal processing and conversion in industrial control systems, ensuring efficient and accurate transmission of data between different devices and systems.
It performs outstandingly in compressor and turbine control applications and is widely used in fields such as oil and gas, electricity, and chemical engineering.
Core functions:
Signal Conversion and Processing
Convert input signals (such as analog and digital signals) into the standard signal format required by the system.
Ensure compatibility and stable transmission of signals in the control system.
Data transmission and communication
Support multiple industrial standard communication protocols (such as Modbus, Profibus, etc.) to achieve data exchange with the upper computer or other modules.
Provide efficient and low latency data transmission to ensure real-time control requirements.
Signal isolation and protection
Provide electrical isolation to prevent signal interference and enhance the system's noise resistance and reliability.
Protect equipment from overvoltage and surge effects.
Modular design
The compact modular design facilitates installation, integration, and maintenance.
Support seamless integration with other CCC control modules to expand system functionality.
High reliability and stability
Industrial grade design, suitable for harsh environments such as high temperature, humidity, vibration, etc.
Capable of long-term stable operation, reducing the risk of system failure.
Technical specifications:
model: TMPU-1002
Function: Signal conversion and isolation
Input signal: Supports multiple analog and digital input formats
Output signal: Standard industrial control signal (such as 4-20mA, 0-10V)
Communication interface:
Modbus
Profibus
Other industrial communication protocols
Electrical isolation: Provide efficient electrical isolation between input/output channels
Power supply voltage: 24V DC
Working temperature:- 40 ° C to+70 ° C
Humidity range: 5% to 95% (non condensing)
Installation method: DIN rail or rack installation
Modular design: supports quick replacement and maintenance

Product details picture:
