Bently 9200-01-02-02-00 Vibration Speed Sensor

Brand: Bently
Model: 9200-01-02-02-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Bently 9200-01-02-02-00 Vibration Speed Sensor

Product manual:

Bently Nevada 9200-01-02-02-00 is a two-wire speed sensor,
Using dynamic coil technology, specifically designed to measure absolute vibration of bearing housings, casings, or structures
Designed relative to free space. This sensor provides a voltage output proportional to the vibration speed,
Suitable for continuous monitoring or use in conjunction with testing or fault diagnosis instruments.
Main features:
Dynamic coil technology: provides voltage output directly proportional to vibration velocity, reducing sensitivity to shock or pulse excitation.
Two wire design: No external power supply required, simplifying portable measurement applications.
Durable and sturdy: Suitable for various industrial environments, ensuring long-term stable operation.
Technical specifications:
Sensitivity: 20 mV/mm/s（500 mV/in/s）±5%
Frequency response: 4.5 Hz to 1 kHz
Installation angle/minimum operating frequency: 0° ± 2.5°，4.5 Hz（270 cpm）
Connector options: Top mounted
Installation base options: circular; 1/4 inch 28 UNF stud
Application areas:
This sensor is widely used in power plants, petrochemicals, aerospace and other fields,
Used to monitor the operating status of large rotating machinery and provide early warning of potential faults.
Its sturdy design ensures long-term use and is an essential tool for geologists or engineers.
