Bently 3500/72M 176449-08 Monitoring Module

Product manual:

major function
Real time pressure monitoring
Capable of accurately measuring the operating pressure of equipment and displaying and analyzing it in real-time through the system.
Provide alarm and danger signals for timely protective measures.
Flexible configuration
Supports multiple input types of pressure sensors (such as 4-20 mA or 0-10 V).
Configurable alarm levels and response thresholds to meet different industrial application requirements.
Modular design
Compatible with Bently Nevada 3500 series frameworks and supports integration with other modules.
Plug in module design, easy to install, disassemble, and maintain.
Alarm function
Provide two independent alarm levels: Warning and Danger.
Support logical voting and event recording functions.
Communication and data integration
Can share data with the system host and support integration with SCADA or DCS systems.
Provide comprehensive data storage and historical analysis capabilities.
technical specifications
model: 3500/72M 176449-08
Input signal: Supports standard pressure sensor signals (such as 4-20 mA).
Alarm output:
Two configurable alarm outputs (warning and danger).
Measurement range:
It can support a wide range of pressure monitoring based on sensor configuration.
Power supply:
Powered by the 3500 series framework, no separate power supply is required.
Environmental conditions:
Working temperature:- 30 ° C to+65 ° C
Relative humidity: 5% -95% (non condensing).
application area
Oil and gas industry
Monitor oil well pressure, oil pipeline pressure, internal pressure of gas turbine, etc.
Power industry
Gas turbine and boiler pressure monitoring.
Chemical and pharmaceutical industries
Pressure measurement and alarm of process equipment.
Industrial manufacturing
Safety management of pressure equipment and gas systems.
Module installation and configuration
Installation method:
Insert the module into the designated slot in the 3500 series rack and use the system configuration tool for initialization and parameter settings.
Configuration tool:
Set up through Bently Nevada 3500 Configuration Software, including sensor type, alarm logic, and response threshold.
