Bently 3500/70M 140734-09 Dynamic Pressure Monitor

Details

Bently 3500/70M 140734-09 Dynamic Pressure Monitor

Product manual:

Bently Nevada 3500/70M (140734-09) Dynamic Pressure Monitor Module
It is a highly specialized monitoring device designed for real-time monitoring of dynamic pressure changes in industrial equipment.
This module is used to detect rapidly changing pressure signals, such as gas turbines
Vibration and shock waves from compressors or other high dynamic pressure equipment to protect the equipment and improve its operational efficiency.
Product Overview
Attribute Details
Model 3500/70M
Order number 140734-09
Equipment type: Dynamic pressure monitor module
Bently Nevada 3500 Series
Main functions: real-time dynamic pressure monitoring, analysis, and alarm
Installation position: Installed in the 3500 frame
Alarm and protection functions:
Equipped with Alert and Danger level alarm functions.
Support custom setting of alarm thresholds to adapt to different devices and applications.
Multi channel input:
Provide multiple pressure sensor input channels, each channel can be configured separately.
Compatible with multiple dynamic pressure sensors.
Modular design:
Support hot swapping, convenient for on-site replacement or upgrade, without the need for downtime.
It can seamlessly integrate with other 3500 series modules to achieve complete device monitoring and protection.
Data analysis and communication:
Can be connected to the system control center to provide real-time data and historical trend records.
Support data bus communication and share data with other modules.
technical parameter
Parameter details
Multiple input channels
Support sensor types, dynamic pressure sensors
Frequency range 0.1 Hz to 10 kHz
Measurement accuracy ± 0.1% or higher
Alarm output alarm and danger alarm, relay triggered
Data output includes dynamic pressure signals and historical data trends
The power supply voltage comes from the 3500 frame power supply
Working temperature -30 ° C to+65 ° C
Storage temperature -40 ° C to+85 ° C
Protection level: Industrial grade durability, high temperature resistance, dust resistance, shock resistance
