Bently 3500/50 286566-02 tachometer module
Product manual:
Bently Nevada 3500/50 (286566-02) Tachometer Module
It is an important module in the Bently Nevada 3500 series used for monitoring the rotational speed of rotating machinery.
It provides critical protection and control functions through monitoring of rotational speed, zero speed, and overspeed, and is suitable for a wide range of industrial fields.
Product Overview
Attribute Details
Model 3500/50
Order number 286566-02
Equipment type Tachometer Module
Bently Nevada 3500 Series
Main functions: speed monitoring, overspeed protection, zero speed detection
Installed in the 3500 frame, it can be used as an independent module
Key features
High precision speed monitoring:
Capable of monitoring the actual rotational speed of rotating machinery and providing real-time data.
Supports a wide measurement range from 1 to 120000 revolutions per minute.
Multiple alarm functions:
Support alarms for zero speed, over speed, and near speed.
Alarm thresholds can be set to achieve flexible monitoring of operational status.
Dual channel design:
Provide two completely independent monitoring channels, suitable for redundant or multi-point monitoring needs.
Flexible input:
Supports various sensor inputs, such as magneto resistive sensors, eddy current probes, and optical sensors.
Supports multiple types of sensor output signals, including TTL and pulse.
technical parameter
Parameter details
Number of channels: 2 channels
Input signal types include TTL, eddy current probe, magneto resistive sensor, etc
Speed range 1 to 120000 RPM
The power supply voltage comes from the 3500 series rack
Alarm output warning and danger alarm, can be triggered by relay
Interface communicates with 3500 display module and data acquisition module
Working environment temperature -30 ° C to+65 ° C
Storage environment temperature -40 ° C to+85 ° C
The protection level meets industrial standards and is suitable for harsh environments
Product details picture:
