ALLEN BRADLEY 1336-QOUT-SP23A Output Tester

Brand:Allen-Bradley
Model: 1336-QOUT-SP23A
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

ALLEN BRADLEY 1336-QOUT-SP23A Output Tester

Product manual:

The Allen Bradley 1336-QOUT-SP23A output tester is a specialized equipment under Rockwell Automation for testing and verifying the output performance of the 1336 series frequency converters. This device is suitable for frequency converter maintenance, troubleshooting, and verification of output signal quality to ensure the normal operation of the frequency converter. It is widely used in industrial automation control systems.

Product Overview
Brand:

Allen Bradley (Rockwell Automation)
model:

1336-QOUT-SP23A
Equipment type:

Output tester, used for testing and diagnosing frequency converter systems.
major function
Output signal test:

Measure and verify the output voltage, frequency, and phase balance of the frequency converter.
Fault diagnosis:

Identify potential issues during the output phase, such as short circuits, overloads, waveform anomalies, etc.
Performance verification:

Ensure the output stability and accuracy of the frequency converter under different load conditions.
Simulated load conditions:

Simulate the actual operating environment and test the output performance of the frequency converter through the built-in load module.
Data recording:

Provide records and analysis of key parameters for subsequent maintenance or improvement.
technical specifications
Detailed parameter information
Applicable equipment Allen Bradley 1336 series frequency converter
Input power standard industrial power supply (AC/DC optional)
Measure parameter output voltage, frequency, phase sequence, waveform quality
Display mode: digital display (equipped with LCD or LED indicator lights)
Test interface standard connection terminals compatible with Allen Bradley devices
Operation mode: automatic testing/manual mode
Data communication supports USB or Ethernet interfaces for connecting to the upper computer
Environmental temperature -10 ° C to+55 ° C
Compact size and weight design for easy portability
