ALCATEL LUCENT 87-1941-01-03- A Control Card

Product manual:

ALCATEL-LUCENT 87-1941-01-03-A Control Card Detailed Explanation
1. Basic information
Model: 87-1941-01-03-A

Manufacturer: Alcatel Lucent (now part of Nokia)

Type: Control Card

Applicable equipment:

Mainly used for optical transmission equipment (such as 1640 FOX/1640 AM)

May be used for SDH/OTN/DWDM systems

Function:

System management, configuration, and control

Alarm monitoring and fault diagnosis

Synchronized clock allocation (such as BIT/GPS)

2. Main characteristics
Control function:

Device initialization and startup management

Software upgrade and backup

Communicate with network management systems (such as 1350 RM/5620 SAM)

Interface type:

Management port (RJ-45/RS-232 Console)

Synchronous clock input/output (e.g. 2MHz/10MHz)

Possible support for Ethernet OAM (for remote management)

Hot swappable support: Some devices support it (specific model needs to be confirmed)

3. Compatible devices
This control card is typically used for the following Alcatel Lucent/Nokia devices:

Optical transmission platform:

1640 FOX (Fiber Optical X-connect)

1640 AM (Access Multiplexer)

SDH/MSPP equipment:

1660 DMX/1662 SMX (further verification required)

⚠️ Attention: For specific compatibility, please refer to the device hardware manual or contact Nokia technical support.

4. Installation and Configuration
Installation steps:

The device is powered off (if it does not support hot swapping).

Insert the control card into the main control slot (usually labeled as Slot A/Slot B).

Connect the management port (Console or ETH) and check the status light after powering on.

Product details picture:
