ALCATEL-LUCENT 3FE29191AA AA 05 Circuit Board

Brand:Alcatel Lucent
Model:3FE29191AA AA 05
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

ALCATEL-LUCENT 3FE29191AA AA 05 Circuit Board

Product manual:

1. Product Overview
Model: 3FE29191AA AA 05
Type: Business Processing/Interface Circuit Board
Purpose: Used for Alcatel Lucent (now Nokia) broadband access or optical transmission equipment, providing business aggregation, protocol conversion, or interface expansion functions.

2. Core functions and features
(1) Interface support
Ethernet interface: 10/100/1000BASE-T (RJ45) or SFP (1G/10G) optical port

Traditional TDM interface: optional support for E1/T1 (for voice or dedicated line services)

Optical transmission interface: may support GPON/XGPON (if used for OLT devices)

(2) Business processing capability
Multi service adaptation: supports IP, MPLS, TDM hybrid services

Traffic management: supports QoS priority scheduling and ACL filtering

Low latency forwarding: hardware accelerated processing, latency<50 μ s

(3) High reliability design
Hot swappable support: can be replaced while the device is running

Redundancy protection: Supports 1+1 backup (requires device architecture support)

(4) Energy saving and heat dissipation
Intelligent power management: dynamically adjust power based on traffic

Fanless design: Some versions use passive cooling

3. Typical application scenarios
(1) Broadband Access Network (FTTx)
As a business card in the 7360 ISAM OLT, it provides GPON/XGS-PON user access

Support the integration of home broadband (HSI), IPTV, and VoIP services

(2) Enterprise dedicated line access
Used for 7705 SAR equipment, providing enterprise Ethernet dedicated line (E-Line/E-LAN)

Support CESoP (Circuit Simulation over Packet) to achieve TDM over IP

(3) Mobile backhaul (IP-RAN)
Carrying CPRI/eCPRI traffic in 4G/5G base station backhaul network

Support 1588v2 clock synchronization

4. Hardware specifications (reference)
Parameter specification description
Size standard single board (specific size depends on the frame)
Power consumption: 30W~75W (depending on the number of activated interfaces)
Working temperature -5 ° C~+55 ° C (commercial grade)
Storage temperature -40 ° C~+70 ° C
Humidity range 5%~95% (non condensing)
