ALCATEL LUCENT 3DH03218ADAA power amplifier module
Brand:Alcatel Lucent
Model:3DH03218ADAA
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
ALCATEL LUCENT 3DH03218ADAA power amplifier module
Product manual:
ALCATEL-LUCENT 3DH03218ADAA Power Amplifier Module Technical Description
Specification
Model: 3DH03218ADAA
Manufacturer: Alcatel Lucent (now under Nokia)
Type: RF power amplifier module
Working frequency band: 1800MHz (DCS frequency band)
Technical Parameter
Output power: 40W (typical value)
Gain: 50dB (minimum)
Efficiency:> 18%
Supply voltage:+ 28VDC
Interface type: N-type connector
major function
Used for base station transmitter system
Provide RF signal amplification
Support Digital Pre Distortion (DPD) technology
Built in over temperature protection circuit
Application scenarios
2G/4G mobile communication base station
indoor distribution system
Wireless relay device
INSTALLATION REQUIREMENTS
Should be installed in a well ventilated environment
Environmental temperature range: -40 ℃ to+55 ℃
Relative humidity: 5% to 95% (non condensing)
Maintenance points
Regularly check the fastening status of connectors
Monitor working temperature
Pay attention to dust and moisture prevention
Security Warning
RF radiation hazard, power off operation is required during installation
Only qualified technicians are allowed to maintain
Must be well grounded
Product details picture:
