ALCATEL LUCENT 3AL86603BFAG Controller Module

Product manual:

ALCATEL-LUCENT 3AL86603BFAG is a Controller Module used in telecommunications grade equipment systems,
Mainly used in Alcatel Lucent's multi service access platform or transmission equipment,
Undertake the management, control, and communication scheduling tasks of the system core.

1、 Basic Product Information
Product model: 3AL86603BFAG

Product Category: Controller Module/CPU Board

Manufacturer: ALCATEL-LUCENT (now part of Nokia)

Equipment series: Typically used for Alcatel 1660 SM
1692 Metrospan, ISAM, 7750 SR and other mid to high end telecommunications equipment

2、 Main functional features
According to the standard design of Alcatel Lucent control modules,
This module may have the following main functions:

1. System main control management function

Control the startup and operation of software and firmware.

2. Network protocol processing
Supports multiple telecommunications protocols such as MPLS, IP, SONET/SDH, Ethernet, TDM, etc.

Handling forwarding strategies, control plane signaling, path selection, etc.

3. Remote management and access
Provide remote configuration, monitoring, and maintenance support
(such as through CLI, SNMP, Telnet, Web, etc.).

Support hot swapping and automatic configuration reload function.

4. Fault diagnosis and system monitoring
Real time monitoring of the status, temperature, voltage, current, etc. of each subsystem.

Trigger an alarm and record a log when a malfunction occurs for troubleshooting purposes.

5. Data security and encryption support (partial versions)
Provide security guidance, access control, link encryption, and other capabilities.

3、 Typical application areas
1. Telecom operator network core layer or aggregation layer equipment
MPLS switching platform applied to Alcatel Lucent
Optical transmission platform or access network control center.

Responsible for scheduling and path control of data flow.

2. Large capacity multi service access system
Like ISAM (Intelligent Services Access Manager)
The core control module in the platform.

Manage DSL GPON、 A large number of end users connected by Ethernet and other access technologies.

Product details picture:
