ALCATEL-LUCENT 3AL78818AAAC Communication Module

Product manual:

This module is a high-performance business processing module in Alcatel Lucent (now Nokia) communication systems, mainly used for optical transmission and packet switching equipment, responsible for business aggregation, protocol conversion, and traffic management functions.

2. Core functional features
Characteristic Technical Description
Multi service support for simultaneous processing of TDM, Ethernet, and IP services, supporting mixed transmission of circuit switching and packet switching
High density interface provides multiple 10G/25G optical or electrical ports, supporting modular interface board expansion
Intelligent traffic management has HQQoS (Hierarchical Quality of Service) and traffic shaping functions, supporting 5 levels of business priority
Hardware accelerated integrated dedicated network processor, supporting MACsec encryption and deep packet inspection (DPI)
The hot swappable design complies with NEBS Level 3 standards and supports online replacement and 1+1 redundant configuration
3. Typical application scenarios
Metropolitan Access Network:

Implementing GPON to metropolitan core network business aggregation in 7350 OLT equipment

Clock synchronization supporting Mobile Backhaul (IP-RAN) (1588v2)

Enterprise dedicated line service:

Provide E1/T1 to Ethernet business conversion

Support VPLS and VPWS layer 2 VPN services

5G network applications:

Front haul network used in CU/DU separation architecture

Support low latency transmission of eCPRI protocol (<100 μ s)

4. Technical specifications and parameters
Physical parameters:

Size: Complies with ATCA standards (8U height)

Power consumption: typical value of 85W, maximum 120W

Heat dissipation: front and rear facing ventilation design

Performance indicators:

Switching capacity: 240Gbps full duplex

Packet forwarding rate: 180Mpps

Delay:< 5 μ s (64 byte group)

Environmental adaptability:

Working temperature:- 40°C ~ +65°C

Humidity: 5%~95% without condensation

5. System compatibility
Supporting equipment:

1830 PSS-32/64 Optical Transmission Platform

7750 SR-12 Service Router

5620 SAM Network Management System

Software requirements:

Should be compatible with Alcatel Lucent OS version 12.O.R6 or above

Support NETCONF/YANG model configuration

Product details picture:
