ABB SYCHROTACT 5 3BHB006716R0277 Automatic Synchronizer

Brand: ABB
Model: SYCHROTACT 5 3BHB006716R0277
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

ABB SYCHROTACT 5 3BHB006716R0277 Automatic Synchronizer

Product manual:

SYCHROTACT 5 3BHB006716R0277 is an automatic synchronizer produced by ABB, used to synchronize generators with the grid or busbar, ensuring safe and accurate grid connection operations. It plays a crucial role in the power system, particularly suitable for power plants, industrial grids, and distributed energy systems.
1. Product Overview
Product model: SYCHROTACT 5 3BHB006716R0277
manufacturer: ABB
Equipment type: Automatic Synchronizer
Application scenario: Synchronize generators with the power grid to ensure safe and accurate grid connection
2. Main features
High precision synchronization:
Real time measurement of voltage, frequency, and phase angle to ensure grid accuracy
Equipped with adjustable synchronization parameters to improve system adaptability
Automated control:
Automatically execute the grid connection process, reduce human intervention, and improve safety
Equipped with manual/automatic working modes
Strong compatibility:
Suitable for different types of generators (synchronous generators, asynchronous generators, etc.)
Compatible with multiple power system architectures
Built in protection function:
It has multiple protection functions such as overvoltage, undervoltage, overclocking, underfrequency, and phase sequence error
Prevent equipment damage caused by misoperation
Communication and Interface:
Supports industrial communication protocols such as Modbus and IEC 61850 (specific model support needs to be confirmed)
Equipped with RS-485, Ethernet and other data interfaces for remote monitoring
3. Technical parameters
Parameter specifications
Input voltage 24V DC or 110-230V AC (depending on the model)
Frequency range 45Hz -65Hz
Synchronization accuracy angle error ≤ 1 °
Communication protocols Modbus, IEC 61850 (supported by some models)
Working temperature -25 ° C~+70 ° C
Installation method: Cabinet installation, DIN rail installation
