ABB IMHSS03 hydraulic servo module

Brand: ABB
Model: IMHSS03
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

ABB IMHSS03 hydraulic servo module

Product manual:

ABB IMHSS03 is a hydraulic servo module used for precise control of actuators in hydraulic systems, such as hydraulic cylinders or hydraulic motors. It is commonly used in industrial automation, metal processing, plastic machinery, machine tool control, and heavy-duty industrial equipment to achieve high-precision hydraulic servo control.
1. Product Overview
manufacturer: ABB（Asea Brown Boveri）
Product model: IMHSS03
Product type: Hydraulic Servo Module
Application areas:
Hydraulic control equipment such as injection molding machines and stamping machines
Hydraulic servo systems for industries such as steel, papermaking, and energy
Other precision hydraulic control applications
2. Technical parameters
Parameter specifications
Control type: Hydraulic servo control
Input voltage 24V DC or higher (depending on system configuration)
The communication interface may support PROFIBUS, Modbus, or CANopen (please refer to the model description for details)
High precision closed-loop hydraulic control with high control accuracy
Compatibility with ABB PLC DCS、 Motion control system
ABB IMHSS03 achieves precise control of hydraulic systems through electronic servo valves or proportional valves, with high dynamic response capability.
3. Main functions
High precision hydraulic control: suitable for complex industrial environments, achieving precise control of pressure, flow rate, and position.
Closed loop feedback system: Combining hydraulic sensors (such as pressure sensors and displacement sensors) to optimize control accuracy.
Modular design: supports quick installation and replacement, suitable for different hydraulic systems.
Intelligent diagnosis and protection: equipped with functions such as fault alarm, overload protection, and pressure anomaly detection.
Strong compatibility: can be integrated into ABB PLC, DCS or industrial control systems.
