704.910.4 Contact block strip

Brand:ABB
Model:704.910.4
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

704.910.4 Contact block strip

Product manual:

1. Product Overview
Model: 704.910.4

Type: Modular Contact Block Strip

Purpose: Auxiliary contact expansion for industrial relays/contactors

Typical brand: Contactor accessories that may correspond to brands such as Siemens, ABB, or Schneider

2. Core Features
Modular design: Multiple contact blocks can be freely combined

Contact type:

Normally open (NO)

Normally closed (NC)

Mixed type (NO+NC)

Electrical parameters:

Rated current: 5-10A (AC-15 category)

Rated voltage: 250VAC/30VDC

Mechanical lifespan: ≥ 1 million operations

3. Structural description
Component Function
The base is fixed to the contactor body
Sliding buckle enables quick assembly of multiple contact blocks
Contact module can be replaced separately (silver alloy contacts)
Wire terminal screw crimping type (wire diameter 0.5-2.5mm ²)
4. Compatibility reference
Possible matching main contactors:

Siemens 3RT/3TF series

Schneider LC1D series

ABB A-series

Installation method:

Side plug-in installation

5. Installation steps
Power off operation: Ensure that the main circuit is completely powered off

Dismantling old modules:

Gently pry open the buckle with a flat screwdriver

Install new module:

Align with the guide rail slot and insert horizontally

The 'click' sound indicates that it is locked in place

Wiring verification:
