57619414A interface inverter board

Brand:ABB
Model:57619414A
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

57619414A interface inverter board

Product manual:

Technical Description of 57619414A Interface Inverter Board
1. Product Overview
Model identification: 57619414A

Equipment type: Interface Inverter Board

Typical applications: Signal conversion and power interface for industrial frequency converters, servo drive systems, or renewable energy converters

2. Core functions
Signal isolation and conversion:

Convert control signals (such as PWM) into isolation signals that drive IGBT/power modules

Support high and low level conversion (such as 3.3V → 15V)

Fault feedback:

Real time monitoring of inverter status (overcurrent, overheating, short circuit) and feedback to the main control unit

Communication interface:

Optional RS485, CAN or fiber optic communication module (specific version needs to be confirmed)

3. Technical parameters
Parameter specifications
Input voltage 24VDC ± 10% (control side)
Maximum output drive capability 2A peak current (IGBT drive)
Isolation voltage 2500Vrms (between input/output)
Response time<500ns (fault signal transmission)
Working temperature -20 ℃~+70 ℃
Protection level IP20 (to be installed inside the electrical cabinet)
4. Interface definition (typical configuration)
Terminal Number Function Remarks
X1.1-X1.3 PWM inputs (+/-/GND) from DSP/FPGA control signals
X2.1-X2.6 IGBT drive output (U/V/W phase) connected to the gate of the power module
X3.1-X3.2 Fault Feedback Signal (NO/NC) Relay Contact Output
X4.1-X4.2 communication interfaces (A/B) support Modbus RTU protocol
