193X565ABG01 PC board
Brand:GE
Model:193X565ABG01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
193X565ABG01 PC board
Product manual:
Product model: 193X565ABG01
Function type: Signal logic processing and control output
Main functions: signal acquisition, data transmission, intermediate control, relay logic switching, etc
Interface form: Gold finger PCB slot connection, compatible with GE 193X backplane system
Power requirement: ± 15V DC/+24V DC (powered by the system)
Onboard components: including logic chips, resistors, capacitors, transistors, potentiometers, small relays, etc
Logic level standard: TTL or CMOS (depending on the chip on the board)
Onboard functional modules: may include voltage detection, comparator, driver, buffer, etc
Working temperature range:- 20°C ~ +70°C
Dimensions: Standard GE 193X series dimensions for easy modular replacement
Installation method: Horizontal plug-in installation, fixed in the system backplane
function
As a signal relay and processing unit between the main control system and the execution module
Implement functions such as logical judgment, command conversion, and state maintenance
Receive system command signals and generate relay or control level signals for output
Preprocess the input signal by filtering, shaping, amplifying, isolating, etc
Collaborate with other modules in the 193X series to complete the entire automatic control logic chain
Application scenarios
Early drive and process control systems such as GE Mark II/IV
Large industrial motor control and excitation system
Automation control system for thermal power plants
Petrochemical plant DCS/PLC control module
High demand automation control site for metallurgy, papermaking, cement and other industries
Installation and maintenance recommendation
Debugging and testing:
After power on, detect the correctness of signal transmission through logic probes/oscilloscopes
If the board is equipped with LED indicator lights, it can preliminarily determine the working status
Check if the connection with adjacent modules is stable to prevent signal interruption
