193X242ABG03 isolation module

Brand:GE
Model:193X242ABG03
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

193X242ABG03 isolation module

Product manual:

193X242ABG03 Isolation Module

product overview
193X242ABG03 is a high-performance isolation module in the GE 193X series control board,
Used to achieve electrical isolation between different signals in industrial automation control systems.
This module can effectively suppress ground loop interference and high-frequency noise, prevent signal crosstalk and voltage backflow,
Improve the security and stability of system operation.

Core functions
Signal isolation: Provides high-level electrical isolation between input and output, effectively preventing interference coupling.

Strong anti-interference ability: using shielding design and optocouplers
Isolation amplifier and other technologies ensure stable data transmission.

Wide signal support: suitable for isolation processing of analog signals (such as voltage, current) or digital signals.

Good system compatibility: can work together with various 193X series cards,
Used in different control architectures.

Technical Parameter
Input signal range: ± 10V, 0-5V, 4-20mA (depending on application configuration)

Output signal type: isolated similar signal output with linear amplification characteristics

Isolation voltage level: 1500V~2500V RMS (input to output)

Response time: Typical<10ms

Accuracy: ± 0.1% F.S

Power supply: ± 15V DC (from the main control rack)

Working temperature:- 20 ° C to+70 ° C

Board structure: Plug in installation, suitable for GE 193X standard slot
