193X228BAG01 auxiliary function board
Brand:GE
Model:193X228BAG01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
193X228BAG01 auxiliary function board
Product manual:
193X228BAG01 Auxiliary Function Board
Product Introduction
193X228BAG01 is an auxiliary function circuit board in the GE 193X series industrial control system,
Used to expand the functions of the main control module, achieve signal interface supplementation, status monitoring, logic control and other functions of the system.
Its design structure supports parallel collaboration with the main control card, improving the compatibility, functionality, and reliability of the control system.
major function
Signal extension: Provides multiple input/output interfaces for collecting or sending control signals.
Logic processing: Integrated logic gate circuits on the board, capable of handling basic control logic tasks,
Such as with, or, non logical judgments.
Status indication: Equipped with LED status display function, easy to debug and troubleshoot.
Protection and isolation: Isolate and filter access signals to enhance anti-interference capabilities,
Prevent system damage.
Communication with the motherboard: Communicate with the main control module through a dedicated bus interface,
Implement synchronous control and status feedback.
Technical Parameter
Power supply: ± 15V or ± 24V DC provided by the system motherboard
I/O interface: multi-channel digital input/output, with buffering and protection circuit
Logic level: TTL or CMOS level compatible
Response time: Typical<1ms, suitable for high-speed signal processing
Working temperature:- 20°C ～ +70°C
Installation method: slot or screw fixed, supporting standard GE architecture cabinets
PCB material: Industrial grade double-sided circuit board with flame retardant and high temperature resistance characteristics
Application scenarios
Auxiliary signal processing for industrial automation control systems
Logic Expansion and Control Instruction Distribution of GE Control System
Supplementary interface for analog/digital hybrid control system
Auxiliary logic processing unit in power automation system
Function expansion board for use with GE 193X control system
Product details picture:
